Brief Introduction

NDR-120-24

The NDR-120 is an economical and low-profile 120W DIN rail power supply that complies with German industry standards and is suitable for installation on the TS-35/7.5 or TS-35/15 The rails, in allowing for space-saving cabinets, the body is designed to be 40 mm wide, and the entire range is available in a full range from 90Vac to 264Vac AC inputs, and all comply with the BS EN/EN61000-3-2 standard for harmonic currents specified by the European Union. The NDR-120 is designed with a metal shell, which is convenient to improve the heat dissipation consumption of the machine, and the working efficiency is up to 89%, and the whole series is under the condition of air circulation Capable of operating at ambient temperatures from -20°C to 70°C, it features constant current mode overload protection for a wide range of inductive or capacitive properties Load application, complete protection function and compliance with the relevant certifications of industrial control equipment (UL508, TUV BS EN/EN62368-1 and others) to enable The NDR-120 becomes a highly competitive power solution for industrial applications
